Power: DC 9V-12V 500mA (min.)
- 192 DMX Channels
- 12 scanners of 16 channels each
- 30 banks of 8 programmable scenes
- 6 programmable chases of 240 scenes
- 8 sliders for manual channel control
- 8- & 16-channel mode
- 1 x 3-pin female/male XLR socket DMX Connectors
- 5-pin multiple socket MIDI Input
Additional Features:
- Assignable joystick for ease of channels
- File dump allows data to be sent or received between two units
- Auto mode program controlled by speedand fade time sliders
- Fade time/assign fade time
- Reversible DMX channels allows fixture to react in opposition to others in a chase
- Fine adjustment for joystick pan and tilt
- Blackout master button
- Manual override button allows you to grab any fixture on the fly
- Built-in microphone for music triggering
- MIDI control over banks, chases and blackout
- DMX polarity selector
- Power failure memory
Code: SC1216
Unit Dimension: 19″ x 5.3″ x 3.4″
Unit Weight: 6 lbs
Shipping Dimensions: 24″ x 9″ x :6″ (Single unit)
Shipping Weight: 9 lbs (Single Unit)
